ROPEX heat seal controller UPT-6011
Current transformer
Category：
Details
Current transformer
Current transformer
Linear filter
Linear filter:
pulse transformer
Pulse transformer is an important part of the whole system. The power and voltage selection of pulse transformer will affect the performance of the whole heat sealing system. The specification selection of pulse transformer depends on the length, cross section and quantity of heat sealing tape controlled by a system. A system can only have one controller with one pulse transformer.
In order to improve the accuracy of the temperature, the customer needs to provide the relevant information about the size of the heating plate and the whole system, and then we will feed back the information to the German ROPEX, so that Germany can select the most suitable transformer and issue a ROPEX electrical report.
Cable
ROPEX standard size:
Current and voltage measuring twisted pair: 2 x 1.0mm ²
Silicone sheath power cord: 4mm ²， 6mm ²， 10mm ²， 16mm ²， 25mm ²
Black skin power cord: 10mm ²， 16mm ²， 25mm ²， 35mm ²
Hot seal cushion
ROPEX standard size:
Silicone pad: 2mm thick, mm wide, hardness 30 °
It can also be customized according to customer size
Working temperature: 250 ℃ - 300 ℃
Insulation layer (Durit): 1mm thick, 12mm wide and 15mm wide
Working temperature: 400 ℃
Silicone glass mat (Siglaha): 1mm thick, 12mm wide and 15mm wide
工作温度：280℃
Cover cloth
ROPEX standard size:
Width: 10mm-100mm
Thickness: 0.13mm, 0.08mm
Width without glue in the middle: 12mm, 15mm
It can also be customized according to customer size.
